Non-solvent laminator Compact type “LMC-SF1300”

SOBU Machinery Co., Ltd.
ノンソルベントラミネータコンパクトタイプLMC-SF1300

<Features>
・Operation considerable design, Operator work burden reduction by an automatic control system
・Safety considerable design at operating
・Possible for uniform processing on a substrate by thickness measurement system (option)

<Specifications>
Machine speed: 400m/min
Substrate width: Max 1300mm
No1, No2 unwinding one axis type diameter: Max φ800mm (Shaftless chucking)
Winding diameter: Max φ1000mm
Coating type: 5 rolls
Tension: 30-300N

Turret type (LM-SF1300T), Dry/non-solvent dual purpose type (LM-Combi-800S) are available.


Contact Information:
30-6 Tanno, Togane, Chiba 283-0824 Japan
TEL.+81-475-55-2135  FAX.+81-475-53-1400
Email:sobu@maple.ocn.ne.jp
URL:http://www.sobukikai.co.jp/

Sales Office:

Products:
Gravure Printing Machines, Flexo Printing Machines, Dry Laminators, Coaters, Other Automated Labor Saving Machinery

To request detailed materials on the above product, please click the contact button below.


CI Flexo Printing Machine “Watergreen”

SOBU Machinery Co., Ltd.
CIフレキソ印刷機-Watergreen

<Features>
・Production ratio improvement in short run
・Printing quality improvement
・Printing loss reduction
・High speed stability improvement

<Specifications of a test machine>
Color : 4 colors
Printing speed: Max 400m/min
Substrate width: 300-960mm
Guide roll length: 1000mm
Printing repeatable length (Plate cylinder periphery): 370-900mm
Unwinding/Rewinding: Single axis fixed double side holding type
Unwinding/Rewinding diameter: Maxφ800mm (3 inch, 6 inch core)
Plate cylinder: Anilox roll・air sleeve type, Sectional drive, anilox
Roll contacting pressure adjustment・Positioning control by stepping motor
Doctor device: Doctor chamber type (Cleaning circulation type)
Drying: Max 120℃, 40m3/min x 3 sets


Contact Information:
30-6 Tanno, Togane, Chiba 283-0824 Japan
TEL.+81-475-55-2135  FAX.+81-475-53-1400
Email:sobu@maple.ocn.ne.jp
URL:http://www.sobukikai.co.jp/

Sales Office:

Products:
Gravure Printing Machines, Flexo Printing Machines, Dry Laminators, Coaters, Other Automated Labor Saving Machinery

To request detailed materials on the above product, please click the contact button below.


SGX Series Follow-up Gravure Printing Press

SOBU Machinery Co., Ltd.
追い刷グラビア印刷機 SGXシリーズ

Characteristics:
-Reduces operator workload via an automatic control system and a design that considers operability. The design also fully considers safety during operations.
-Comes equipped with a high-precision compensatorless sectional drive system for follow-up printing. Using a sensor attached to the inside of the device, the machine adjusts to pitch error in existing printed matter for high-precision follow-up printing.
-Realizes fully automated high-precision splicing for follow-up printing that matches with existing printed matter.

Specifications:
Substrates: various plastic films, paper
Maximum Machine Speed: 220 m/min
Substrate Width: 900, 1,000, 1,100, 1,200, 1,300 mm
Original Roll Diameter: 600 mm
Original Roll Support: shaftless
Splicing: fully automated high-precision splicing for follow-up printing
Tension Control: Automated AC vector inverter motor control
Registration Control: compensatorless sectional drive system, automatic vertical/horizontal registration control (initial positioning system)
Drying Method: quick return method
Drying Heat Source: LPG gas, steam, electric heating, etc.
Other specifications designed to meet customer needs


Contact Information:
30-6 Tanno, Togane, Chiba 283-0824 Japan
TEL.+81-475-55-2135  FAX.+81-475-53-1400
Email:sobu@maple.ocn.ne.jp
URL:http://www.sobukikai.co.jp/

Sales Office:

Products:
Gravure Printing Machines, Flexo Printing Machines, Dry Laminators, Coaters, Other Automated Labor Saving Machinery

To request detailed materials on the above product, please click the contact button below.
